McHale Trailed Bale Wrappers

Part #: McHale-991BW
The McHale 991 Range sets the pace for efficient and effective round bale wrapping. Practical design, quality components and precision engineering make the 991 Range the first choice for contractors and farmers who want a high quality and consistent performance in all types of conditions and terrain.
Details

McHale Round Bale Wrappers

The McHale 991 Range sets the pace for efficient and effective round bale wrapping. Practical design, quality components and precision engineering make the 991 Range the first choice for contractors and farmers who want a high quality and consistent performance in all types of conditions and terrain. Packed with practical and reliable features the 991 Range is designed with the efficient operator in mind. Look for the hydraulically operated cut and tie system, the efficient dispenser, (which maximizes film usage) and the 991’s patented ground supported damper system and you will see why you will look to the 991 Range for your choice. Like all McHale Bale wrappers, the high output 991 Range will give you a tightly wrapped bale that contains all the natural juices for increased nutritional value while improving environmental protection.



DAMPER SYSTEM - The uniquely designed McHale Patented Bale Damper system is probably one of the most important features of the McHale machine. Only a McHale Bale wrapper will give you a ground supported bale damper, which will gently lower the bale to the ground and at the same time eliminate all stress to the chassis. When the rotating table stops and is raised to the tip position, the heavy duty bale damper raises to cradle the bale while a second arm is lowered automatically to the ground. This allows the heaviest of bales to be gently lowered eliminating any damage.

CUT & TIE - The McHale hydraulically operated Cut and Tie System cuts and holds the film in position ready to wrap the next bale. This time saving device eliminates the need to manually reattach the film. Uniquely designed, this system works reliably and consistently in all weather conditions.

Features (All Models)

  • 750mm Film Dispenser
  • Cut and Tie System
  • Patented Ground Supported Damper
  • Wide Low Ground Pressure Tires
  • Film Roll Holders
  • Self Loading Arm
  • Counter Balance Weight
  • Bale Support Bobbins
  • Shear Bolt Unit

Model 991B/BC Features

  • 4 Lever Control
  • 3.5 Meter Cables (BC model)
  • Auto Stop Function (BC model)

Model 991BJS Features

  • Single Lever Servo Joystick Control (Fully functional single lever joystick operation with smooth transition between functions and easy movement due to low pressure servo hydraulic control).
  • Automatic Cut and Hold Release

Model 991BE Features

  • Fully Automated Electronic Control Unit allows the user to select from 3 Cycle Options;
    1. Automatic Wrapping Cycle
    2. Automatic Load and Wrap Cycle
    3. Automatic Load – Wrap and Tip Cycle
  • Auto Load Lift Arm Function
  • Film Break Sensor



  All Models
 Transport Length 19'
 Transport Width 8' 2"
 Height to Top of Rollers 4' 2"
 Overall Height 8' 1"
 Weight 4123 lbs
 Lift Capacity 2425 lbs
 Working Speed up to 30 rpm
 Attachment to Tractor Tow Bar
 Film Layers 2+2 or 2+2+2
 Hydraulic Requirement 5.8 gpm
 Hydraulic Connections 2 x 1/2"
Model Driver Control
 991B/BC 4 Lever Control
 991BJS Single Lever Joystick
 991BE Electronic Control Unit
 991BER Electronic Control Unit w/Remote

Model Electrical Requirements
 991B/BC 12v/ 7 pin
 991BJS 12v/ Euro-plug
 991BE 12v/ from battery
 991BER 12v/ from battery
