Grasshopper 600 Series
Part #: 600
Grasshopper 600 Series FrontMount models feature a three-wheeled power unit with the cutting deck mounted forward of both the engine and operator's seat. The unit has a single wheel located at the rear of the unit, behind the engine
Details
Videos
FrontMount mowers complete complex mowing jobs faster. Low-profile outfront decks reach under shrubs and fences, reducing trimming, allowing you to save time on high-acreage jobs with speeds up to 8.5 mph. A complete line of professional-quality, year-round implements provides all-season versatility.
600 Series options include:
· CoolTemp Cordura® ComfortZone™ seat with lumbar support
· Extended steering levers
· Wide seat conversion kit
· Bar tread tires (for 623T)
· Dual-forktail wheels or wide stance single-fork tail wheels
· PowerFold®/Electric Height Adjustment for 48- and 52-inch (121.9 cm) or (132.1 cm) DuraMax® decks
· Full flotation deck feature
· Hour meter (standard on 623T)
· Mulching package
· PowerVac™ Collection Systems
· QuikConverter™ Implement capability
600 Series options include:
· CoolTemp Cordura® ComfortZone™ seat with lumbar support
· Extended steering levers
· Wide seat conversion kit
· Bar tread tires (for 623T)
· Dual-forktail wheels or wide stance single-fork tail wheels
· PowerFold®/Electric Height Adjustment for 48- and 52-inch (121.9 cm) or (132.1 cm) DuraMax® decks
· Full flotation deck feature
· Hour meter (standard on 623T)
· Mulching package
· PowerVac™ Collection Systems
· QuikConverter™ Implement capability
| Model | 616T | 620T |
| Engine Manufacturer | Briggs & Stratton Vanguard | Kohler Command |
| Engine Horsepower | 16 hp | 20 hp |
| Available Deck Sizes | 44" / 48" | 48" / 52" |
| Cutting Height | 1" - 5" | 1" - 5" |
| Fuel Capacity | 4.3 gal. | 4.3 gal. |
| Speed (Forward/Reverse) | 0-8.0 mph / 0-5.5 mph | 0-8.5 mph / 0-5.5 mph |
| Transmission | T-Drive hydrostatic | T-Drive hydrostatic |
| Overall Width (Side Discharge) | 57.5" / 61.5" | 61.5" / 65.5" |
| Overall Width (Mulch) | 45.5" / 49.5" | 49.5" / 53.5" |
| Overall Length | 96.5" / 99" | 99" / 100" |
| Overall Height (ROPS) | 63" | 63" |
| Turning Radius | true zero degree | true zero degree |
