Sweepster Tow-Behind Broom

Part #: Tow Behind Broom
Hydraulic brush drive eliminates high maintenance chains and sprockets on brush drive
Details
TBTD Series Tow-Behind Angle Brooms

Applications

  • Street sweeping
  • Highway sweeping
  • Bike and hiking path sweeping
  • Sweeping for seal coating and paving work
  • Sweeping snow and debris at small airports
Features
  • Hydraulic brush drive eliminates high maintenance chains and sprockets on brush drive
  • Large 32" diameter 84" wide brush is standard
  • Two wheel design for easy maneuverability and towing
  • Fast interchange between towing vehicles
  • No additional engine required or hydraulic hookups to truck required
  • Quick Change brush with out breaking hydraulic lines
  • Brush core is reversible end to end
  • Heavy duty replaceable hex brush drive
Model Width Brush Dia. Weight
TD7 84" 32" 2300 lbs
TD8 96" 32" 2350 lbs
TD9 108" 32" 2400 lbs




TBTH Series Tow-Behind Angle Brooms

  • Powered by two orbital hydraulic motors mounted inside brush frame, coupled to core by keyed, tapered shaft
  • Requires 17 gpm at 2000 psi hydraulic system to operate
  • Two, three and four-wheel base configurations available
  • Pintle, ball or drop pin hitch
  • Manually angles 30° left or right
  • Choose poly, poly/wire or wire brush
Model Width Brush Dia. Weight
TBTH7 84" 32" 1650 lbs
TBTH8 96" 32" 1700 lbs
TBTH9 108" 32" 1750 lbs




TBH Series Tow-Behind Angle Brooms

  • Powered by two orbital hydraulic motors mounted inside brush frame, coupled to core by keyed, tapered shaft
  • Closed loop hydrostatic pump mounts directly to engine
  • In-cab control box operates brush angle, lift, speed and engine start/stop
  • Two, three and four-wheel base configurations available
  • Pintle, ball or drop pin hitch
  • Hydraulically angles 30° left or right
  • Fenders, standard
  • Choose poly, poly/wire or wire brush
Model Width Brush Dia. Weight
TBH7 84" 32" 2550 lbs
TBH8 96" 32" 2600 lbs
TBH9 108" 32" 2650 lbs
