Grouser AG220 Row Crop Blade

Part #: GAG220
 These systems are ideal for 100-370 horsepower row crop tractors and will give you exceptional versatility and ease of use in the yard and the field.
Details

Get lifting heights that OEM configurations simply cannot match with our AG Series blade systems, accessories and hitches. These systems are ideal for 100-370 horsepower row crop tractors and will give you exceptional versatility and ease of use in the yard and the field.

Features

  • 36" Lift Height
  • 15" Under Tractor Clearance
  • Includes Grouser Front Hitch
  • Quick Connect & Disconnect at the blade
  • Adjustable Skid Shoes
  • Available for mounting on OEM or aftermarket front hitches

Specifications

  • 4" X 20" Angle Cylinder (optional)
  • 4" X 8" Tilt Cylinder (optional)
  • 4" X 12" Lift Cylinder
  • 5/8" X 6" reversible cutting edge
  • Blade angles 30 degrees right or left (optional)
  • Blade tilts 10 degrees (optional)
  • Width's available from 8' (m) to 16' (m)
  • Blade height 54"
  • 3/16" thick moldboard
