New Holland ProTed Rotary Tedder

Part #: ProTed
Don’t risk ruined hay! Improve your odds and bale or chop sooner—before it rains—with the help of a New Holland ProTed rotary tedder.
Details
Files

PROTED ROTARY TEDDERS – THE GENTLE WAY TO DRY HAY

Don’t risk ruined hay! Improve your odds and bale or chop sooner—before it rains—with the help of a New Holland ProTed™ rotary tedder. Models ranging from 17’1” to 36’ 1”tedding width, the ProTed is the right choice for your application.

GENTLE FLUFFING ACTION

A ProTed rotary tedder helps you make high-quality hay even in difficult weather conditions. Tedding “fluffs” your crop and distributes it evenly to expose damp hay to sunlight and air, which carries the moisture away. This speeds drying time so you can bale before bad weather hits. If showers hit unexpectedly, use your ProTed tedder to spread damp hay for quick drying. The tines used on the ProTed tedders offer stability, flexibility, and longevity. They are also adjustable to provide optimum spreading and fluffing.

HEAVY DUTY RELIABILITY

All three ProTed models feature our new, heavy-duty, boxed-frame design and the ProTed™ modular rotor-gearbox. Unlike lesser designs, ProTed rotor gearboxes do not serve as part of the frame. They are bolted to the strong, fully welded main fame. The gearboxes feature reliable crown-and-pinion drives. The ProTed 3114 requires periodic greasing, but permanent oil bath lubrication on the two larger models simplifies daily maintenance. Large drive shafts and double universal joints transmit power through the frame allowing each rotor to track your field contours with precision. The hexagonal drive shaft profile eliminates keys and keyways which can weaken the shaft or fail under heavy crop loads.



  ProTed 3417 ProTed 3625 ProTed 3836
Tedding Width 17' 1" 24' 11" 36' 1"
Transport Width 9' 6" 9' 9" 9' 9"
Number of Rotors 4 6 8
Tine Arms per Rotor 6 7 7
Tractor Requirement 20 hp 50 hp 60 hp
