New Holland Rotary Tillers

Part #: NH-RTiller
Get your seedbeds ready for planting and control weeds between rows with a capable rotary tiller. They're built to handle the daily demands of gardeners, nursery owners, landscapers and small farm owners, and are available in widths up to 72 inches so you can get more done with each pass.
Details

New Holland Rotary Tillers

  • MULTI-TASK ON EACH PASS - Get your seedbeds ready for planting and control weeds between rows with a capable rotary tiller. They're built to handle the daily demands of gardeners, nursery owners, landscapers and small farm owners, and are available in widths up to 72 inches so you can get more done with each pass.
  • DURABLE COMPONENTS, FLEXIBLE OPERATION - The sturdy deck is constructed of steel and connects to your tractor's three-point hitch by a box section steel frame. Outside hitch pin brackets are adjustable for offset operations so you can till close to obstacles or buildings.
  • POWER PROTECTION - The 540-rpm PTO (Power Take Off) is slip-clutch protected to prevent driveline component damage.
  • LONG LIFE AND SMOOTH PERFORMANCE - Grease fittings mean longer life for driveline universal joints and rotor shaft bearings. And both the input gearbox and side gearbox run in oil for smooth power transmission and superior durability.
  • ADJUSTMENTS TO MATCH YOUR SOIL - Convenient chain support makes adjusting shield height quick and easy. Simply lower it to thoroughly pulverize the soil, or raise it for coarser textures. Skid shoes also adjust to one of four settings to control tilling depths of 0"-5".
  • UPGRADE WITH HD MODELS - Choose a heavy-duty model and get one-pass tilling with a powerful gearbox and high-speed tines with greater tip speed. Plus, these models support both Category I and II three-point hitches.



  Model 105A
 Working Width 60" 72"
 Max Tilling Depth w/Guide Shoe 4.5" 4.5"
 Max Tilling Depth w/o Guide Shoe 7.25" 7.25"
 Drivetrain Chain Chain
 Hitch Cat.1 Cat.1
 Offset Adjustment to Right 11" 11"
 PTO HP Rating 45 hp 45 hp
 Rotor Speed 236 rpm 236 rpm
 Number of Blades 28 36
 Blade Tip Speed 1063 fpm 1063 fpm
