NH Loader Backhoes

Part #: NH-TLB
New C Series loader backhoes with Tier 4 Final certified engines deliver the power and torque needed so you can dig, load, trench or push faster, while reducing the impact on the environment.
Details
Files

New Holland Loader Backhoes - C Series

MAINTENANCE-FREE BRAKES

Outboard wet disc brakes with separate Spring Applied Hydraulically Released (SAHR) parking brake provide enhanced control and significantly increased brake life. The “low effort” braking system allows the operator to apply stopping power with a minimum amount of force

POWERSHUTTLE OR POWERSHIFT TRANSMISSION

Choose from our robust Power Shuttle and our advanced Powershift. Our reliable PowerShuttle transmission is easy to operate, with a right-hand gear shift lever and convenient FNR shuttle lever. Choose Powershift transmission for maximum operator comfort. Operators appreciate the convenience of the powershift transmission that shifts smoothly up or down through the gears automatically locating the correct gear for the conditions

OUTSTANDING LOADER BUCKET BREAKOUT

By using a straight arm loader design, C series Loader backhoes deliver unmatched loader lift capacities and the loader bucket location on top of the loader frame produces exceptional bucket breakout forces.

FAST, COMPLETE SERVICE ACCESS

The tilt-forward hood and checkpoints that are grouped together reduce maintenance time so you can maximize uptime and profits.



Model B95C B95C TC B95C LR B110C
Gross Horsepower 97 hp 97 hp 97 hp 110 hp
Base Unit Weight 17,560 lbs 17,730 lbs 18,525 lbs 18,525 lbs
Loader Heaped Capacity 1.1 cu.yd. 1.3 cu.yd. 1.1 cu.yd. 1.3 cu.yd.
Max Loader Height 14' 0" 13' 11" 14' 0" 14' 2"
Max Backhoe Dig Depth 14' 6" 14' 6" 15' 6" 15' 6"
Max Backhoe Reach 18' 4" 18' 4" 19' 3" 19' 3"
