FFC Snow Blades

Part #: FFCSBlade
FFC's Snow Blades efficiently move large volumes of snow. They are also ideal for wastewater, manure, feed lots, and flow cleanup.
Details
Series Width Height Angle
 114 Series 48"-96" 23" 30°
 115 Series 84"-144" 32" 35°
 136 Series 84"-108" 33" 30°
 5700 Series 84"-144" 32" 30°



114 Series Snow Blades

Ideal for the small to mid-range skid steers with universal skid steer mount only. This versatile snow blade comes with a mold board trip mechanism, 30-degree angle left/right in manual or hydraulic angle. The snow blade also comes standard with (2) I-bolts, which can be swapped out with the trip springs for a light dozing application.

  • For Skid Steers, Compact Tool Carriers, and Compact Utility Loaders
  • 48"-96" cutting widths available
  • Hydraulically or manually angles 30 degrees in either direction
  • Reversible, replaceable wear edge; optional rubber edge
  • Adjustable skid shoes
  • Optional spring-loaded trip mechanism
  • Seven-gauge steel blade

115 Series Snow Blades

Ideal for the largest skid steers and tractor backhoe loaders, this versatile snow blade has a much larger mold board for larger capacity and widths, ranging from 84" to 144", hydraulic angle 35 degrees left/right. This unit has options for steel, rubber or polyurethane cutting edges.

  • For Large SSL, Compact Utility Loaders, Small Wheel Loaders and Backhoe Loaders
  • 84"-144" cutting widths available
  • Hydraulically angles 35 degrees in either direction
  • Replaceable bolt-on wear edge
  • Optional rubber edge
  • Skid shoes with adjustable height
  • Reinforced seven-gauge steel blade
  • Spring-loaded trip mechanism

136 Series Snow Blades

FFC's Snow Blades efficiently move large volumes of snow. Ideal for wastewater, manure, feed lots, and flow cleanup. Optional pull-back kit draws snow from buildings, fences and confined areas. Cutting edge trip system allows operator to glide over manholes and curbs without losing gathered materials.

  • For Skid Steers
  • 84"-108" cutting widths available
  • Hydraulically angles 30° in either direction
  • Reversible and replaceable wear edge
  • Adjustable skid-shoes
  • Spring-loaded trip mechanism
  • 23” 7-gauge steel blade
  • Heavy structural steel frame
  • Standard hydraulic angle
  • Optional manual angle
  • Optional rubber wear edge

5700 Series Snow Blades

The 5700 Series angles 30º in either direction hydraulically. Blade is made from reinforced ten gauge steel.

  • For SSL, Compact Utility Loaders, and Backhoe Loaders
  • 84"-144" cutting widths available
  • Reversible and replaceable wear edge
  • Adjustable skid shoes
  • Spring-loaded trip mechanism
  • Heavy structural steel frame
  • Standard hydraulic angle
  • Optional rubber wear edgev
