600TL Utility Loaders
Part #: NH-600TL
When you team the 600TL Series front-end loader with your New Holland tractor, you get the perfect combination of power and versatility for all your lifting, hauling moving and landscaping chores.
Details
New Holland 600TL Utility Loaders
A MATCH MADE IN HEAVEN
When you team the 600TL Series front-end loader with your New Holland tractor, you get the perfect combination of power and versatility for all your lifting, hauling moving and landscaping chores. An ergonomic joystick makes operation easy, and a choice of attachments lets you customize it to the task at hand.
CLEAR SIGHTLINES
The low-profile design allows maximum visibility when operating in tight spaces.
Compatibility
- 611TL - Workmaster™ 50, 60, 70
- 616TL - Workmaster™ 50, 60, 70
- 621TL - Workmaster™ 50, 60, 70 / T4.80F, T4.90F, T4.100F, T4.110F
- 622TL - PowerStar 65, 75
- 626TL - Workmaster™ 50, 60, 70 / T4.80F, T4.90F, T4.100F, T4.110F
- 627TL - PowerStar 65, 75
- 632TL - PowerStar 90, 100, 110, 120 / T4.90, T4.100, T4.110, T4.120 / T5.90, T5.100, T5.110, T5.120
- 637TL - PowerStar 90, 100, 110, 120 / T4.90, T4.100, T4.110, T4.120 / T5.90, T5.100, T5.110, T5.120
Non Self-Leveling Models
| 611TL | 615TL | 621TL | 622TL | 625TL | 632TL | |
| Self-Leveling | No | No | No | No | No | No |
| Max Lift Height | 112" | 111" | 119" | 115" | 126" | 120" |
| Lift Capacity @ pivot pin | 3263 lbs | 3461 lbs | 3880 lbs | -- | 3450 lbs | -- |
| Lift Capacity @ 31.5" forward | -- | -- | -- | 1936 lbs | -- | 2028 lbs |
| Breakout Force @ pivot pin | 4629 lbs | 4299 lbs | 4894 lbs | 4928 lbs | 4670 lbs | 5247 lbs |
| Max Dump Angle | 43° | 43° | 42° | 53° | 37° | 52° |
| Bucket Roll Back Angle | 27° | 23° | 27° | 45° | 24° | 44° |
Mechanical Self-Leveling Models
| 616TL | 626TL | 627TL | 637TL | |
| Self-Leveling | Mechanical | Mechanical | Mechanical | Mechanical |
| Max Lift Height | 122" | 130" | 115" | 120" |
| Lift Capacity @ pivot pin | 2623 lbs | 3130 lbs | -- | -- |
| Lift Capacity @ 31.5" forward | -- | -- | 2728 lbs | 3175 lbs |
| Breakout Force @ pivot pin | 3439 lbs | 4034 lbs | 4026 lbs | 4387 lbs |
| Max Dump Angle | 40° | 46° | 53° | 52° |
| Bucket Roll Back Angle | 30° | 45° | 45° | 44° |
 |
|
