WORKMASTER 95, 105, 120 Tractors
New Holland WORKMASTER Tractors - AG Series
THE TRADITION OF VALUE CONTINUES
WORKMASTER™ tractors meet the needs of a wide range of customers. Designed for those with a keen eye for value, the NEW WORKMASTER 95, 105 and 120 provide unmatched comfort, simplicity and visibility with a low cost of ownership.
EQUIPPED JUST THE WAY YOU NEED IT
WORKMASTER 95, 105, and 120 tractors are ready to complete any task with the productivity of the 12x12 hydraulic power shuttle transmission and four-wheel drive. All three models are available with the WORKMASTER cab, or choose the open-air, ROPS platform, available in All-Purpose, Low-Profile and Poultry configurations.
VERSATILE UTILITY
WORKMASTER Series tractors are the perfect fit for the many jobs on dairy, livestock and mixed farms. These Value-focused, high-performance, utility tractors are a blend of everything you want—the power to handle your tough jobs, the ability to work effectively in tight places and the ease and comfort you crave.
POWERFULLY EFFICIENT
WORKMASTER 95, 105 and 120 tractors are powered by 207-cubic-inch (3.4L), 4-cylinder engines built by Fiat Powertrain Technologies (FPT). These free breathing engines use 4 values per cylinder and a high pressure common rail, direct injected, electronically controlled, fuel system to deliver clean, fuel-efficient power.
| WORKMASTER 95 | WORKMASTER 105 | WORKMASTER 120 | |
| Engine | |||
| Type | 4 cyl. F5 Diesel | 4 cyl. F5 Diesel | 4 cyl. F5 Diesel |
| Gross Engine HP | 97 hp | 112 hp | 120 hp |
| PTO HP | 78 hp | 92 hp | 100 hp |
| Displacement | 207 in³ | 207 in³ | 207 in³ |
| Transmission | |||
| Standard | 12x12 Power Shuttle | ||
| Hydraulics | |||
| Implement Pump | 16.9 gpm | ||
| Service Pump | 9.7 gpm | ||
| Rear Remotes | 2 or 3 | ||
| Hitch | |||
| Lift Capacity @ 24" | 3200 lbs | ||
| Optional Ram @ 24" | 6200 lbs | ||
| Dimensions | |||
| Wheelbase, Cab | 88.9" | ||
| Wheelbase, ROPS | 83.7" | ||
| Height, top of Cab | 105.4" | ||
| Height, top of ROPS | 103.0" | ||
| Overall Length | 161.1" | ||
| Opt. Front Loaders | 632TL (Non Self-Leveling) 637TL (Mechanical Self-Leveling) |
||
 |
