Jacto Air Blast Trailed Sprayers

Part #: Jacto-ATS
Jacto Air Blast sprayers for orchards, vineyards, berries, Christmas trees, nurseries, and citrus groves are unsurpassed for coverage and easy maintenance. We utilize the worlds finest ceramic cylinder high-pressure piston pumps, combined with our own control valves for the most efficient operation.
Details

Jacto Air Blast Trailed Sprayers

Jacto Air Blast sprayers for orchards, vineyards, berries, Christmas trees, nurseries, and citrus groves are unsurpassed for coverage and easy maintenance.



Jacto utilizes the world's finest ceramic cylinder high-pressure piston pumps, combined with our own control valves for the most efficient operation. All models are equipped with flip-over nozzles for quick changes of application rates. Jacto fans are individually tailored to the specific model needs. They are equipped with variable pitch, fiberglass-reinforced nylon blades, and a clutch with a lockout mechanism so the fan can be turned off during filling, mixing, and hand-spraying. Independent tests have shown Jacto Airblast Sprayers are unequalled when it comes to efficient and effective chemical delivery and crop protection.



 Model Arbus 500 Arbus 1000 Arbus 1500 Arbus 2000 Arbus 4000
 Tank Capacity 150 gal. 265 gal. 400 gal. 530 gal. 1057 gal.
 Tank Material Polyethylene Fiberglass Polyethylene Fiberglass Polyethylene
 Chemical Solution Agitation Hydraulic w/Venturi Mechanical/Bypass Mechanical/Bypass Mechanical/Bypass Mechanical/Hydraulic
 Spray Pump Flow Rate 13 gpm 20 gpm 40 gpm 50 gpm 40/50/80 gpm
 Maximum Pressure 300 psi 300 psi 300 psi 300 psi 300 psi
 Fan Air Speed 48 mph 94 mph 75 or 83 mph 78 mph 65 mph
 Max Air Volume 192 cfs 342 cfs 491 cfs 847 cfs 636 cfs
 Dimensions (LxWxH) 111" x 49" x 46" 142" x 56" x 55" 158" x 75" x 58-67" 175" x 73" x 80" 214" x 83" x 98"
