DuraVee Trailing Wheel Rakes

Part #: DuraVee
New Holland DuraVee trailing wheel rakes are the right choice for high-capacity haymakers looking for a fast way to move more hay. Offered in seven models with raking widths up to 36 feet.
Details

New Holland Wheel Rakes - DuraVee Series

THE FAST WAY TO MOVE MORE HAY

New Holland DuraVee™ trailing wheel rakes are the right choice for high-capacity haymakers looking for a fast way to move more hay. Offered in seven models with raking widths from 17’ 5” to 36’, these rakes are perfect for many different sizes of haymaking operations. Simple adjustments mean you rake all of your crop and head down the road quickly when you’re finished. Strengthened components, like thick frames and heavy-gauge steel tubing for wheel supports, enhance durability so DuraVee rakes withstand high-speed operation in varying field conditions.

THE STRAIGHT AND NARROW PATH TO ROADING

All DuraVee™ rakes have 15” tires and can fold down to 8’3” for easy road transportation. To enhance safety and eliminate shimmying, transport safety locks and adjustable friction disc brake brakes on the caster wheels are featured on all models.



Model 817 1020 1225 1428 1631 1833 2036
Number of Rake Wheels 8 10 12 14 16 18 20
Tines per Wheel 40 40 40 40 40 40 40
Rake Wheel Diameter 55" 55" 55" or 60" 55" or 60" 55" or 60" 55" 55"
Maximum Working Width 17' 5" 20' 4" 25' 28' 6" 31' 33' 5" 36'
Transport Width 8'3 8'3 8'3 8'3 8'3 8'3 8'3
Tractor Requirement 30 hp 30 hp 40 hp 40 hp 40 hp 55 hp 55 hp
